Product highlights

HURRY ONLY 4 LEFT!

  • 30A PWM Regulator
  • Lithium battery activation function
  • Fully 3-stage PWM charge management
  • Dual USB ports
  • Suitable for Flooded, AGM, GEL and Lithium batteries

Have a question? Ask our experts!

Product details

Our solar charge controller is definitely born to guarantee full control of electrical flows and protection. It features PWM 3-stage charging process--bulk, absorption and float stage-- for a rapid, intelligent and safe charging to batteries including Lead acid, AGM And Gel. Over temperature protection, over current, over power, low voltage, over voltage are integrated to safeguard your solar panel. And overcharging, over-discharging . dual USB ports are designed to offer more convenience in charging electronic devices. Last but not the least, it features a large screen LCD display which is controlled by intelligent chip With low power consumption and long life. Providing you a real-time view of the input, output and battery conditions.

To properly wire your solar charge controller, click here.


Technical specs

SPECIFICATIONS

Material: ABS
System voltage: 12V / 24V Auto
Rated charge current: 30A
Max Solar Input: <50V
Float charge voltage: 13.7V (adjustable)
Discharge stop: 10.7V (adjustable)
Discharge reconnect: 12.6V (adjustable)
Suitable battery: Flooded, AGM, GEL, & Lithium batteries
USB output: 5V/2A
Operating temperature: -35°-60°
Self-consume: <10mA
Colour: Blue and black

DIMENSIONS & WEIGHT

Dimensions: 133 x 70 x 34mm
Weight: 154g

WHAT'S IN THE BOX

1 x PWM Controller
