Selling fast Selling fast. Hurry and order now to save 28%

Product highlights

  • 2048Wh Capacity
  • 2200W AC Pure Sine Wave Inverter (4,800W Surge)
  • LiFePO4 Battery with 3500+ Life Cycles to 80%
  • Expandable Up To 6144Wh with 2 x B230, or 8,192Wh with 2×B300
  • 7 Ways to Recharge (AC/Solar/Car/Generator/Lead Battery/Dual AC/AC+Solar)

Have a question? Ask our experts!

Product details

All-round Upgraded Expandable Power Station
BLUETTI first expandable power station-AC200MAX with 2,048Wh LiFePO? cells and 2,200W pure sine wave inverter. Your mobile power center at home or on the way.

Less To Spend, More To Love
Struggling between power and flexibility? We got you covered! With two expansion ports, The AC200MAX welcomes up to two BLUETTI B230’s(2048Wh each) or B300(3072Wh each) battery modules, connecting of which can boost the total capacity to a staggering 8192Wh!

Get Charged In Anyway You Prefer
The AC200MAX allows up to 900W of solar input and 500W via the adapter, you can even charge it up via your wall outlet and solar panels simultaneously, boost a stunning 1400W total charging rate which can top up your power beast in less than two hours! Further more, every BLUETTI battery module has their own input port for AC adapters, you’ll get another 500W of input capability with every module added (Up to two for the AC200MAX).

Small Change, Huge Leap
The AC200Max can now take one module via its solar input port with a converter cable for extra capacity!

Incomparable Outlet Versatility
With AC200MAX’s 15 outlets, you get to run all your needs simultaneously without breaking a sweat.


How-to

A useful guide to making the most of it all.

How to recharge ACMax via solar panels



How to connect ACMAX with either B230 or B300 Battery Modules



How to use the Touchscreen of AC200Max


Technical specs

BATTERY INFO

Battery Capacity: 2048Wh (51.2V,40Ah)
Battery Cell Type: LiFePO4 (Lithium Iron Phosphate)
Rated Life Cycle: 3,500+ Cycles to 80% Original Capacity
Shelf-life: Recharge to 80% Every 3-6 Months
Management System: MPPT Controller, BMS, etc
Pass-through Charging: Yes
Operating Temperature: -4-104℉ (-20-40℃)
Storage Temperature: 14-113℉ (-10-45℃)
Tested & Certifications: UL Standard, CEC, DOE, FCC, CA Prop 65
Warranty: 48 Months

OUTPUT

AC Outlets: 4 x 220V-240V,2200W In Total
Inverter Type: Pure Sine Wave
Surge Power: 4800W
USB-C Port: 1 x 100W Max.
USB-A Port: 2 x 5V/3A USB-A
2 x 18W USB-A
12V DC Outlets: 1 x 12V/30A (RV Outlet)
1 x 12V/10A (Car Outlet)
2 x 12V/10A DC 5521 (5.5mm Outlet)
*All Regulated.
Wireless Charging Pad: 2 x 15W Max. (For Each)

INPUT

AC Adapter Input: 500W.
Solar Input: 900W Max.OCV 10-145VDC, 15A
Car Input: 12/24V from Cigarette Lighter Port
Max Input: 1,400W, with AC+Solar Input

RECHARGE TIMES

AC Adapter (500W): ≈5.5~6 Hours
Solar (900W): ≈3~3.5 Hours (With prime sunshine, ideal orientation and low temperature)
12V/24V Car Outlet (100W/200W): ≈10 or 20 Hours
AC Adapter + Solar (1400W): ≈2.0~2.5 Hours (With prime sunshine, ideal orientation and low temperature)
Dual AC Adapters (1000W): ≈3~3.5 Hours (Extra adapter is REQUIRED)

DIMENSIONS & WEIGHT

Dimensions (LxWxD): 16.5 x 11 x 15.2 in ( 42 x 28 x 38.65cm)
Weight: 61.9lbs (28.1kg)

WHAT'S IN THE BOX

1 x AC200MAX Power Station
1 x T400 AC Adapter & Cable
1 x PV Charging Cable (MC4-TX90)
1 x Car Charging Cable (XT90 - Charging Lighter Port)
1 x XT90 TO Aviation Plug (Input)
1 x User Manual
1 x Warranty Card
1 x Certificate of QC Pass

SKU

bt_ac200max
